| Número da peça | AA121TH01-DE1 |
| Marca | Mitsubishi |
| Tamanho | 12.1 |
| Aplicativo | IA |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | 400 |
| CR | 1000:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | Mitsubishi |
| modelo de painel | AA121TH01-DE1 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 12.1 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | IPS, Normally Black, Transmissive |
| área ativa | 261.12×163.2 mm |
| contorno | 303×205.1×16.3 mm |
| superfície | Clear, Hard coating (5H) |
| brilho | 400 cd/m² (Typ.) |
| taxa de contraste | 1000:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| tempo de resposta | 12/12 (Typ.)(Tr/Td) |
| ângulo de visão | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (1 ch, 8-bit), 20 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | IA |
