| Número da peça | AA170EC01 |
| Marca | Mitsubishi |
| Tamanho | 17.0 |
| Aplicativo | IA |
| Resolução | 1280×1024 |
| Composição | LCM |
| Brilho | 600 |
| CR | 800:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | Mitsubishi |
| modelo de painel | AA170EC01 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 17.0 inch |
| resolução | 1280(RGB)×1024 , SXGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 337.92×270.336 mm |
| contorno | 358.5×296.5×17.4 mm |
| superfície | Antiglare, Hard coating (3H) |
| brilho | 600 cd/m² (Typ.) |
| taxa de contraste | 800:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 8-bit), CIE193172% |
| tempo de resposta | 6/19 (Typ.)(Tr/Td) |
| ângulo de visão | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 4 stringsWLEDWithout Driver |
| interface de sinal | LVDS (2 ch, 6/8-bit), 30 pins |
| tensão de entrada | 3.3/5.0V (Typ.)(VCC) |
| aplicativo | IA |
