| Número da peça | BP080WX1-100 |
| Marca | BOE |
| Tamanho | 8.0 |
| Aplicativo | PAD |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | |
| CR | 900:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | MIPI |
| marca do painel | BOE |
| modelo de painel | BP080WX1-100 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 8.0 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | HFFS, Normally Black, Transmissive |
| área ativa | 172.224×107.64 mm |
| superfície | Hard coating (3H) |
| brilho | |
| taxa de contraste | 900:1 (Typ.) |
| exibir cores | 16.7M (6-bit + Hi-FRC) |
| tempo de resposta | 24 (Typ.)(Tr+Td) |
| ângulo de visão | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | WLED |
| interface de sinal | MIPI (4 data lanes) |
| aplicativo | PAD |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| BP080WX7-100 | BOE | 8.0 | 1280×800 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
| B080UAN01.4 | AUO | 8.0 | 1200×1920 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HX121WX1-103 | HYDIS | 12.1 | 1280×800 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
