| Número da peça | HSD121PHW1-A03 |
| Marca | HannStar |
| Tamanho | 12.1 |
| Aplicativo | NBPC |
| Resolução | 1366×768 |
| Composição | LCM |
| Brilho | 200 |
| CR | 500:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | HannStar |
| modelo de painel | HSD121PHW1-A03 1 Compatible model |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 12.1 inch |
| resolução | 1366(RGB)×768 , WXGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 268.01×150.68 mm |
| contorno | 279×167.2×5.1 mm |
| estilo de forma | Wedge (PCBA Bent, Depth ≥5.2mm) |
| superfície | Glare (Haze 0%), Hard coating (3H) |
| brilho | 200 cd/m² (Typ.) |
| taxa de contraste | 500:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193150% |
| tempo de resposta | 3/9 (Typ.)(Tr/Td) |
| ângulo de visão | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (1 ch, 6-bit), 30 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | NBPC |
| G121I1-L01 | Innolux | 12.1 | 1280×800 |
| HSD121PHW1-A01 | HannStar | 12.1 | 1366×768 |
| HSD121PHW1-A03 | HannStar | 12.1 | 1366×768 |
| HSD121PHW2-A00 | HannStar | 12.1 | 1366×768 |
| HSD121PS11-A | HannStar | 12.1 | 800×600 |
| LLB121ST01 | Samsung | 12.1 | 800×600 |
| LT121AC62000 | TOSHIBA | 12.1 | 1024×768 |
| LTM12C283 | TOSHIBA | 12.1 | 800×600 |
| LTN121XJ-L05 | Samsung | 12.1 | 1024×768 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
| B160HW02 V0 | AUO | 16.0 | 1920×1080 |
| LT141DEQ8B00 | TOSHIBA | 14.1 | 1440×900 |
| LTM12C278F | TOSHIBA | 12.1 | 800×600 |
| LTN154P3-L02 | Samsung | 15.4 | 1680×1050 |
| LTN156AT02-A04 | Samsung | 15.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N133BGE-L21 | Innolux | 13.3 | 1366×768 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| N140B6-L02 | Innolux | 14.0 | 1366×768 |
| N156BGE-E41 | Innolux | 15.6 | 1366×768 |
