| Número da peça | LAM170M023A |
| Marca | JDI |
| Tamanho | 17.0 |
| Aplicativo | MD |
| Resolução | 1280×1024 |
| Composição | LCM |
| Brilho | 240 |
| CR | 900:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | JDI |
| modelo de painel | LAM170M023A |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 17.0 inch |
| resolução | 1280(RGB)×1024 , SXGA |
| modo de exibição | IPS, Normally Black, Transmissive |
| área ativa | 337.92×270.336 mm |
| contorno | 368×306×20.4 mm |
| superfície | Antiglare, Hard coating (2H) |
| brilho | 240 cd/m² (Typ.) |
| taxa de contraste | 900:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193174% |
| tempo de resposta | 10/12 (Typ.)(Tr/Td) |
| ângulo de visão | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 3 stringsWLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (2 ch, 8-bit), 30 pins |
| tensão de entrada | 5.0V (Typ.) |
| aplicativo | MD |
