| Número da peça | LQ043T3DG02 |
| Marca | SHARP |
| Tamanho | 4.3 |
| Aplicativo | PND |
| Resolução | 480×272 |
| Composição | LCM |
| Brilho | 480 |
| CR | 900:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | SHARP |
| modelo de painel | LQ043T3DG02 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 4.3 inch |
| resolução | 480×272(RGB) , WQVGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 95.04×53.856 mm |
| contorno | 105.5×67.2 mm |
| superfície | Antiglare, Hard coating (2H) |
| brilho | 480 cd/m² (Typ.) |
| taxa de contraste | 900:1 (Typ.) |
| exibir cores | 262K (6-bit) |
| tempo de resposta | 8/21 (Typ.)(Tr/Td) |
| ângulo de visão | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | 9S1PWLED |
| interface de sinal | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| tensão de entrada | 3.15/3.15V (Typ.)(VDDIO/VCI) |
| rohs: | |
| aplicativo | PND |
