| Número da peça | LTN154XB-L01 |
| Marca | Samsung |
| Tamanho | 15.4 |
| Aplicativo | NBPC |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | 500 |
| CR | 600:1 |
| cores | 262K |
| luz de fundo | CCFL |
| Interface | LVDS |
| marca do painel | SAMSUNG |
| modelo de painel | LTN154XB-L01 3 Compatible model |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 15.4 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 331.2×207 mm |
| contorno | 344×225×7 mm |
| estilo de forma | Wedge (PCBA Bent, Depth ≥5.2mm) |
| superfície | Glare (Haze 0%), Hard coating (3H) |
| brilho | 500 cd/m² (Typ.) |
| taxa de contraste | 600:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193190% |
| tempo de resposta | 16 (Typ.)(Tr+Td) |
| ângulo de visão | 70/70/65/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 2 pcsCCFLWithout Driver |
| interface de sinal | LVDS (1 ch, 6-bit), 30 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | NBPC |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN154AT09-201 | Samsung | 15.4 | 1280×800 |
| LTN154AT12-D01 | Samsung | 15.4 | 1280×800 |
| LTN154AT13-701 | Samsung | 15.4 | 1280×800 |
| LTN154BT05-001 | Samsung | 15.4 | 1440×900 |
| LTN154MT02-W01 | Samsung | 15.4 | 1680×1050 |
| LTN154U1-L02 | Samsung | 15.4 | 1920×1200 |
| LTN154X1-L01 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L04 | Samsung | 15.4 | 1280×800 |
| LTN154XB-L01 | Samsung | 15.4 | 1280×800 |
| B133EW03 V0 | AUO | 13.3 | 1280×800 |
| LP133WX2-TLG1 | LG Display | 13.3 | 1280×800 |
| LP140WX1-TL01 | LG Display | 14.0 | 1280×768 |
| LQ121S1LH03 | SHARP | 12.1 | 800×600 |
| LTD111EWAS | TOSHIBA | 11.1 | 1366×768 |
| LTN133AT27-205 | Samsung | 13.3 | 1366×768 |
| LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
| N133HSE-E21 | Innolux | 13.3 | 1920×1080 |
| N140BGN-E42 | Innolux | 14.0 | 1366×768 |
| N140FGE-EA2 | Innolux | 14.0 | 1600×900 |
