| Número da peça | N080ICE-GB0 Rev.C2 |
| Marca | Innolux |
| Tamanho | 8.0 |
| Aplicativo | PAD |
| Resolução | 800×1280 |
| Composição | LCM |
| Brilho | 400 |
| CR | 1000:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | MIPI |
| marca do painel | INNOLUX |
| modelo de painel | N080ICE-GB0 Rev.C2 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 8.0 inch |
| resolução | 800(RGB)×1280 , WXGA |
| modo de exibição | AAS, Normally Black, Transmissive |
| área ativa | 107.64×172.224 mm |
| contorno | 114.6×184.1×3.85 mm |
| superfície | Glare (Haze 0%), Hard coating |
| brilho | 400 cd/m² (Typ.) |
| taxa de contraste | 1000:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193160% |
| tempo de resposta | 25 (Typ.)(Tr+Td) |
| ângulo de visão | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 5 stringsWLEDWithout Driver |
| interface de sinal | MIPI (4 data lanes) |
| tensão de entrada | 1.8/3.3V (Typ.)(VDDI/VCI) |
| aplicativo | PAD |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB1 | Innolux | 8.0 | 800×1280 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLAA | LG Display | 9.7 | 1024×768 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LT101MB02000 | JDI | 10.1 | 1920×1200 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
