| Número da peça | N101ICE-G62 |
| Marca | Innolux |
| Tamanho | 10.1 |
| Aplicativo | PAD |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | 350 |
| CR | 800:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | MIPI |
| marca do painel | INNOLUX |
| modelo de painel | N101ICE-G62 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 10.1 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | AAS, Normally Black, Transmissive |
| área ativa | 216.96×135.6 mm |
| contorno | 228.6×149.2×4.6 mm |
| superfície | Glare (Haze 0%), Hard coating (3H) |
| brilho | 350 cd/m² (Typ.) |
| taxa de contraste | 800:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193150% |
| tempo de resposta | 10/15 (Typ.)(Tr/Td) |
| ângulo de visão | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 6 stringsWLEDWithout Driver |
| interface de sinal | MIPI (4 data lanes), 39 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | PAD |
