| Número da peça | NL12876BC15-01 |
| Marca | NLT |
| Tamanho | 8.9 |
| Aplicativo | NBPC |
| Resolução | 1280×768 |
| Composição | LCM |
| Brilho | 280 |
| CR | 500:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL12876BC15-01 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 8.9 inch |
| resolução | 1280(RGB)×768 , WXGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 193.92×116.352 mm |
| contorno | 209.2×130.3×7.7 mm |
| superfície | Clear, Hard coating (3H) |
| brilho | 280 cd/m² (Typ.) |
| taxa de contraste | 500:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193156% |
| tempo de resposta | 6/2 (Typ.)(Tr/Td) |
| ângulo de visão | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 11S3PWLEDWithout Driver |
| interface de sinal | LVDS (1 ch, 6-bit), 30 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | NBPC |
