| Número da peça | NL160120AC27-32B |
| Marca | NLT |
| Tamanho | 21.3 |
| Aplicativo | MD |
| Resolução | 1600×1200 |
| Composição | LCM |
| Brilho | 760 |
| CR | 1200:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL160120AC27-32B |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 21.3 inch |
| resolução | 1600(RGB)×1200 , UXGA |
| modo de exibição | UA-SFT, Normally Black, Transmissive |
| área ativa | 432×324 mm |
| contorno | 457×350×23 mm |
| superfície | Antiglare, Hard coating (2H) |
| brilho | 760 cd/m² (Typ.) |
| taxa de contraste | 1200:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193172% |
| tempo de resposta | 20/20 (Typ.)(Tr/Td) |
| ângulo de visão | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (2 ch, 8-bit), 30 pins |
| tensão de entrada | 12.0V (Typ.) |
| aplicativo | MD |
