| Número da peça | NL192108AC10-01D |
| Marca | NLT |
| Tamanho | 9.0 |
| Aplicativo | IA |
| Resolução | 1920×1080 |
| Composição | LCM |
| Brilho | 400 |
| CR | 700:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | NLT |
| modelo de painel | NL192108AC10-01D |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 9.0 inch |
| resolução | 1920(RGB)×1080 , FHD |
| modo de exibição | UA-SFT, Normally Black, Transmissive |
| área ativa | 198.72×111.78 mm |
| contorno | 214.6×130×9.6 mm |
| superfície | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| brilho | 400 cd/m² (Typ.) |
| taxa de contraste | 700:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| tempo de resposta | 13/12 (Typ.)(Tr/Td) |
| ângulo de visão | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (2 ch, 6/8-bit), 50 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | IA |
