| Número da peça | P070BAG-CM1 |
| Marca | Innolux |
| Tamanho | 7.0 |
| Aplicativo | CNS |
| Resolução | 1024×600 |
| Composição | LCM |
| Brilho | 500 |
| CR | 800:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | INNOLUX |
| modelo de painel | P070BAG-CM1 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 7.0 inch |
| resolução | 1024(RGB)×600 , WSVGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 154.214×85.92 mm |
| contorno | 164.9×100×5.1 mm |
| superfície | Hard coating |
| brilho | 500 cd/m² (Typ.) |
| taxa de contraste | 800:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193170% |
| tempo de resposta | 10/15 (Typ.)(Tr/Td) |
| ângulo de visão | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDWithout Driver |
| interface de sinal | LVDS (1 ch, 6/8-bit), 40 pins |
| tensão de entrada | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplicativo | CNS |
