| Número da peça | TM080VDSP01 |
| Marca | Tianma |
| Tamanho | 8.0 |
| Aplicativo | PAD |
| Resolução | 1200×1920 |
| Composição | LCM |
| Brilho | 390 |
| CR | 900:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | MIPI |
| marca do painel | TIANMA |
| modelo de painel | TM080VDSP01 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 8.0 inch |
| resolução | 1200(RGB)×1920 , WUXGA |
| modo de exibição | SFT, Normally Black, Transmissive |
| área ativa | 107.64×172.224 mm |
| contorno | 114.6×184.1×2.3 mm |
| superfície | |
| brilho | 390 cd/m² (Typ.) |
| taxa de contraste | 900:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193160% |
| tempo de resposta | 25 (Typ.)(Tr+Td) |
| ângulo de visão | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 7S3PWLEDWithout Driver |
| interface de sinal | MIPI (4 data lanes), 31 pins |
| tensão de entrada | 3.3/10.0/18.0/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicativo | PAD |
