| Número da peça | BT140GW02 V.0 |
| Marca | Innolux |
| Tamanho | 14.0 |
| Aplicativo | NBPC |
| Resolução | 1366×768 |
| Composição | LCM |
| Brilho | 220 |
| CR | 500:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | INNOLUX |
| modelo de painel | BT140GW02 V.0 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 14.0 inch |
| resolução | 1366(RGB)×768 , WXGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 309.399×173.952 mm |
| contorno | 323.5×192×5.2 mm |
| estilo de forma | Wedge (PCBA Bent, Depth ≥5.2mm) |
| superfície | Antiglare, Hard coating (3H) |
| brilho | 220 cd/m² (Typ.) |
| taxa de contraste | 500:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193160% |
| tempo de resposta | 8 (Typ.)(Tr+Td) |
| ângulo de visão | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (1 ch, 6-bit), 40 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | NBPC |
| B140XW01 V9 | AUO | 14.0 | 1366×768 |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.4 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.5 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.A | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.9 | Innolux | 14.0 | 1366×768 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| N140BGE-L32 | Innolux | 14.0 | 1366×768 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B133XTN01.6 HW0A | AUO | 13.3 | 1366×768 |
| B140XTN02.4 | AUO | 14.0 | 1366×768 |
| HSD121PHW1-A03 | HannStar | 12.1 | 1366×768 |
| LP133WP1-TJAA | LG Display | 13.3 | 1440×900 |
| LQ164D1LA4B | SHARP | 16.4 | 1600×900 |
| LTD121LA3SG-201 | TOSHIBA | 12.1 | 1024×768 |
| LTN121AP03-001 | Samsung | 12.1 | 1280×800 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| N156B6-L07 | Innolux | 15.6 | 1366×768 |
