| Número da peça | DLC0900DIG-1 |
| Marca | Other |
| Tamanho | 9.0 |
| Aplicativo | IA |
| Resolução | 800×480 |
| Composição | LCM |
| Brilho | 1000 |
| CR | 500:1 |
| cores | 262K/16.2M |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | DLC |
| modelo de painel | DLC0900DIG-1 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 9.0 inch |
| resolução | 800(RGB)×480 , WVGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 198×111.696 mm |
| contorno | 210.7×126.4×5.7 mm |
| superfície | |
| brilho | 1000 cd/m² (Typ.) |
| taxa de contraste | 500:1 (Typ.) |
| exibir cores | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| tempo de resposta | 10/15 (Typ.)(Tr/Td) |
| ângulo de visão | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | WLEDWithout Driver |
| interface de sinal | TTL (1 ch, 6/8-bit), 50 pins |
| tensão de entrada | 3.3/10.4/17.0/-5.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplicativo | IA |
| AA090AA01 | Mitsubishi | 9.0 | 960×540 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| DLC0900DIG-1 | Other | 9.0 | 800×480 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| NL8048BC24-14NH | NLT | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| G238HAN01.0 | AUO | 23.8 | 1920×1080 |
| LM8V301 | SHARP | 7.7 | 640×480 |
| LTA057A340F | TOSHIBA | 5.7 | 320×240 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| NL8060BC31-47 | NLT | 12.1 | 800×600 |
| PD064VT2 | E Ink | 6.4 | 640×480 |
| RGS11096064YW000 | RiTdisplay | 1.1 | 96×64 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
