| Número da peça | E555HBM2 |
| Marca | EDO |
| Tamanho | 5.5 |
| Aplicativo | MPH |
| Resolução | 720×1280 |
| Composição | OLED |
| Brilho | 300 |
| CR | 3000:1 |
| cores | 16.7M |
| luz de fundo | self |
| Interface | MIPI |
| marca do painel | EDO |
| modelo de painel | E555HBM2 |
| tipo de painel | AM-OLED , OLED |
| tamanho do painel | 5.5 inch |
| resolução | 720(RGB)×1280 , WXGA |
| área ativa | 69.12×122.88 mm |
| contorno | 72.8×131.2 mm |
| superfície | |
| brilho | 300 cd/m² (Typ.) |
| taxa de contraste | 3000 : 1 (Min.) |
| exibir cores | 16.7M (8-bit), CIE1931105% |
| ângulo de visão | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| motorista ic | COG Built-in SH1386 |
| interface de sinal | MIPI (4 data lanes), 30 pins |
| tensão de entrada | 3.3/4.6/6.1/-3.5V (Typ.)(VCI/VELVDD/VSP/VELVSS) |
| aplicativo | MPH |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LH550WF2-SD01 | LG Display | 5.5 | 1080×1920 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
| ACX435AKN-7 | SONY | 4.5 | 800×1280 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| EJ030NC-02A | Innolux | 3.0 | |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| LH350WS1-SD01 | LG Display | 3.5 | 640×960 |
| LMS241GF31 | Samsung | 2.4 | 240×320 |
| LS030Q7DH01 | SHARP | 3.0 | 240×320 |
| LS055T1SX01 | SHARP | 5.5 | 1080×1920 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
