| Número da peça | HSD043I9W1-A00-R0 |
| Marca | HannStar |
| Tamanho | 4.3 |
| Aplicativo | PND |
| Resolução | 480×272 |
| Composição | LCM |
| Brilho | 400 |
| CR | 600:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | HannStar |
| modelo de painel | HSD043I9W1-A00-R0 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 4.3 inch |
| resolução | 480(RGB)×272 , WQVGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 95.04×53.856 mm |
| contorno | 105.5×67.2 mm |
| superfície | Antiglare, Hard coating (3H) |
| brilho | 400 cd/m² (Typ.) |
| taxa de contraste | 600:1 (Typ.) |
| exibir cores | 16.7M (8-bit) |
| tempo de resposta | 3/7 (Typ.)(Tr/Td) |
| ângulo de visão | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | 6S2PWLEDWithout Driver |
| interface de sinal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | PND |
