| Número da peça | HX121WX1-100 |
| Marca | HYDIS |
| Tamanho | 12.1 |
| Aplicativo | PAD |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | 300 |
| CR | 700:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | BOE HYDIS |
| modelo de painel | HX121WX1-100 1 Compatible model |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 12.1 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | AFFS, Normally Black, Transflective |
| área ativa | 261.12×163.2 mm |
| contorno | 276.8×180×6.8 mm |
| superfície | Hard coating (2H), Antireflection |
| brilho | 300 cd/m² (Typ.) |
| taxa de contraste | 700:1 (Typ.)(Transmissive) |
| exibir cores | 262K (6-bit), CIE193142% |
| tempo de resposta | 30 (Typ.)(Tr+Td) |
| ângulo de visão | 90/90/90/90 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 12S4PWLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (1 ch, 6-bit), 40 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | PAD |
