| Número da peça | LAJ080W001A |
| Marca | TPO |
| Tamanho | 8.0 |
| Aplicativo | CNS |
| Resolução | 800×480 |
| Composição | LCM |
| Brilho | |
| CR | 500:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | TPO |
| modelo de painel | LAJ080W001A |
| tipo de painel | LTPS TFT-LCD , LCM |
| tamanho do painel | 8.0 inch |
| resolução | 800(RGB)×480 , WVGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 174×104.4 mm |
| superfície | |
| brilho | |
| taxa de contraste | 500:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193150% |
| tempo de resposta | 4.5/7.5 (Typ.)(Tr/Td) |
| ângulo de visão | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | WLEDWithout Driver |
| interface de sinal | Parallel RGB (1 ch, 6-bit), 60 pins |
| aplicativo | CNS |
