| Número da peça | LTM170EU-A01 |
| Marca | Samsung |
| Tamanho | 17.0 |
| Aplicativo | DMPC |
| Resolução | 1280×1024 |
| Composição | LCM |
| Brilho | 270 |
| CR | 400:1 |
| cores | 16.2M |
| luz de fundo | CCFL |
| Interface | Analog |
| marca do painel | SAMSUNG |
| modelo de painel | LTM170EU-A01 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 17.0 inch |
| resolução | 1280(RGB)×1024 , SXGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 337.92×270.336 mm |
| contorno | 358.5×296.5×25.4 mm |
| superfície | Antiglare (Haze 25%), Hard coating (3H) |
| brilho | 270 cd/m² (Typ.) |
| taxa de contraste | 400:1 (Typ.) |
| exibir cores | 16.2M (6-bit + FRC), CIE193165% |
| tempo de resposta | 5/20 (Typ.)(Tr/Td) |
| ângulo de visão | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 4 pcsCCFLEmbedded (Inverter) |
| interface de sinal | Analog RGB, 27 pins |
| tensão de entrada | 12.0V (Typ.) |
| aplicativo | DMPC |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| HM200WD1-100 | BOE | 20.0 | 1600×900 |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| LM220WE5-TLA1 | LG Display | 22.0 | 1680×1050 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| M260J3-L01 | Innolux | 25.5 | 1920×1200 |
| TX43D14VC0CAB | KOE | 17.0 | 1280×1024 |
