| Número da peça | LTP280QV-E01 |
| Marca | Samsung |
| Tamanho | 2.8 |
| Aplicativo | MPH |
| Resolução | 240×320 |
| Composição | LCM |
| Brilho | 110 |
| CR | 150:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | SAMSUNG |
| modelo de painel | LTP280QV-E01 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 2.8 inch |
| resolução | 240(RGB)×320 , QVGA |
| modo de exibição | TN, Normally White, Transflective |
| área ativa | 43.2×57.6 mm |
| contorno | 52.9×71.7×4.75 mm |
| superfície | Hard coating (3H) |
| brilho | 110 cd/m² (Typ.) |
| taxa de contraste | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| exibir cores | 262K (6-bit), CIE193130% |
| tempo de resposta | 35 (Typ.)(Tr+Td) |
| ângulo de visão | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | 6S1PWLEDWithout Driver |
| interface de sinal | Parallel RGB (1 ch, 6-bit), 61 pins |
| tensão de entrada | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| aplicativo | MPH |
