| Número da peça | NL128102AC28-07 |
| Marca | NLT |
| Tamanho | 18.1 |
| Aplicativo | IA |
| Resolução | 1280×1024 |
| Composição | LCM |
| Brilho | 240 |
| CR | 300:1 |
| cores | 16.7M |
| luz de fundo | CCFL |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL128102AC28-07 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 18.1 inch |
| resolução | 1280(RGB)×1024 , SXGA |
| modo de exibição | A-SFT, Normally Black, Transmissive |
| área ativa | 359.04×287.232 mm |
| contorno | 389×317.2×31.3 mm |
| superfície | Hard coating (2H), Antireflection |
| brilho | 240 cd/m² (Typ.) |
| taxa de contraste | 300:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193160% |
| tempo de resposta | 15/14 (Typ.)(Tr+Td) |
| ângulo de visão | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 12 pcsCCFLEmbedded (Inverter) |
| interface de sinal | LVDS (2 ch, 8-bit), 50 pins |
| tensão de entrada | 12.0V (Typ.) |
| aplicativo | IA |
