| Número da peça | NL8060BC21-02 |
| Marca | NLT |
| Tamanho | 8.4 |
| Aplicativo | IA |
| Resolução | 800×600 |
| Composição | LCM |
| Brilho | 400 |
| CR | 600:1 |
| cores | 262K/16.7M |
| luz de fundo | CCFL |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL8060BC21-02 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 8.4 inch |
| resolução | 800(RGB)×600 , SVGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 170.4×127.8 mm |
| contorno | 200×152 mm |
| superfície | Clear, Hard coating (3H) |
| brilho | 400 cd/m² (Typ.) |
| taxa de contraste | 600:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| tempo de resposta | 6/19 (Typ.)(Tr/Td) |
| ângulo de visão | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 2 pcsCCFLWithout Driver |
| interface de sinal | LVDS (1 ch, 6/8-bit), 20 pins |
| tensão de entrada | 3.3V (Typ.) |
| rohs: | |
| aplicativo | IA |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| NL8060BC26-28 | NLT | 10.4 | 800×600 |
| NL8060BC26-30C | NLT | 10.4 | 800×600 |
| NL8060BC31-27 | NLT | 12.1 | 800×600 |
| NL8060BC31-28D | NLT | 12.1 | 800×600 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| EL240.128.45 CC | Lumineq | 4.8 | 240×128 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| LB121S03-TL02 | LG Display | 12.1 | 800×600 |
| LJ64H034 | SHARP | 8.9 | 640×400 |
| LM64C35P | SHARP | 10.4 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| RX215-C10 | ROGIN | 21.5 | 1920×1080 |
| TCG121SVLQAPNN-AN20 | Kyocera | 12.1 | 800×600 |
| UG-2832TLBGG01 | WiseChip | 1.0 | 128×32 |
