| Número da peça | TD035SHED1 |
| Marca | TPO |
| Tamanho | 3.5 |
| Aplicativo | MPH |
| Resolução | 480×640 |
| Composição | LCM |
| Brilho | 170 |
| CR | 200:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | TPO |
| modelo de painel | TD035SHED1 |
| tipo de painel | LTPS TFT-LCD , LCM |
| tamanho do painel | 3.5 inch |
| resolução | 480(RGB)×640 , VGA |
| modo de exibição | TN, Normally White, Transflective |
| área ativa | 53.28×71.04 mm |
| contorno | 64×85 mm |
| superfície | |
| brilho | 170 cd/m² (Typ.) |
| taxa de contraste | 200:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| exibir cores | 262K (6-bit), CIE193137% |
| tempo de resposta | 35 (Typ.)(Tr+Td) |
| ângulo de visão | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | 6S1PWLEDWithout Driver |
| interface de sinal | Parallel RGB (1 ch, 6-bit) + SPI, 51 pins |
| tensão de entrada | 3.0/3.0V (Typ.)(VDC/VDDIO) |
| aplicativo | MPH |
