| Número da peça | TX31D200VM0BAA |
| Marca | KOE |
| Tamanho | 12.3 |
| Aplicativo | IA |
| Resolução | 1280×480 |
| Composição | LCM |
| Brilho | 1000 |
| CR | 1000:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | KOE |
| modelo de painel | TX31D200VM0BAA |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 12.3 inch |
| resolução | 1280(RGB)×480 , DVGA |
| modo de exibição | IPS, Normally Black, Transmissive |
| área ativa | 291.84×109.44 mm |
| contorno | 320×130×12.6 mm |
| superfície | Antiglare |
| brilho | 1000 cd/m² (Typ.) |
| taxa de contraste | 1000:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193170% |
| tempo de resposta | 25 (Typ.)(Tr+Td) |
| ângulo de visão | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (1 ch, 6-bit), 20 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | IA |
