| Número da peça | N070ICG-LD3 |
| Marca | Innolux |
| Tamanho | 7.0 |
| Aplicativo | UMPC |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | |
| CR | 800:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | CHIMEI INNOLUX |
| modelo de painel | N070ICG-LD3 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 7.0 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | IPS, Normally Black, Transmissive |
| área ativa | 149.76×93.6 mm |
| superfície | |
| brilho | |
| taxa de contraste | 800:1 (Typ.) |
| exibir cores | 262K (6-bit) |
| tempo de resposta | 13/12 (Typ.)(Tr/Td) |
| ângulo de visão | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLED |
| interface de sinal | LVDS (1 ch, 6-bit) |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | UMPC |
