| Número da peça | N070ICG-LD1 |
| Marca | Innolux |
| Tamanho | 7.0 |
| Aplicativo | UMPC |
| Resolução | 1280×800 |
| Composição | LCM |
| Brilho | 400 |
| CR | 800:1 |
| cores | 16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | CHIMEI INNOLUX |
| modelo de painel | N070ICG-LD1 1 Compatible model |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 7.0 inch |
| resolução | 1280(RGB)×800 , WXGA |
| modo de exibição | IPS, Normally Black, Transmissive |
| área ativa | 149.76×93.6 mm |
| contorno | 161×107×4.5 mm |
| superfície | Glare (Haze 0%), Hard coating (3H) |
| brilho | 400 cd/m² (Typ.) |
| taxa de contraste | 800:1 (Typ.) |
| exibir cores | 16.7M (8-bit), CIE193150% |
| tempo de resposta | 14/11 (Typ.)(Tr/Td) |
| ângulo de visão | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 9S2PWLEDEmbedded (LED Driver) |
| interface de sinal | LVDS (1 ch, 8-bit), 39 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | UMPC |
| HSD070IDW1-A21 | HannStar | 7.0 | 800×480 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| LD070WS2-SL06 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LTD056ET0T | TOSHIBA | 5.6 | 1024×600 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
| LTL070AL01-L01 | Samsung | 7.0 | 1280×800 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| N070Y1-T01 | Innolux | 7.0 | 800×480 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
