| Número da peça | NL10276AC28-05R |
| Marca | NLT |
| Tamanho | 14.1 |
| Aplicativo | DMPC |
| Resolução | 1024×768 |
| Composição | LCM |
| Brilho | 220 |
| CR | 150:1 |
| cores | 262K |
| luz de fundo | CCFL |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL10276AC28-05R |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 14.1 inch |
| resolução | 1024(RGB)×768 , XGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 285.696×214.272 mm |
| contorno | 330×255×20.5 mm |
| superfície | Antiglare, Hard coating (3H) |
| brilho | 220 cd/m² (Typ.) |
| taxa de contraste | 150:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193140% |
| tempo de resposta | 11/40 (Typ.)(Tr/Td) |
| ângulo de visão | 50/50/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lâmpada | 2 pcsCCFLEmbedded (Inverter) |
| interface de sinal | LVDS (1 ch, 6-bit), 20 pins |
| tensão de entrada | 5.0V (Typ.) |
| aplicativo | DMPC |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| NL10276BC16-06 | NLT | 8.4 | 1024×768 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL10276BC20-08 | NLT | 10.4 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL10276BC30-34D | NLT | 15.0 | 1024×768 |
| CLAA150XP01Q | CPT | 15.0 | 1024×768 |
| HT170EX1-101 | BOE | 17.0 | 1280×1024 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| LTM230HT10 | Samsung | 23.0 | 1920×1080 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
| M156MWR1 R0 | IVO | 15.6 | 1366×768 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
