| Número da peça | NL10276BC13-01C |
| Marca | NLT |
| Tamanho | 6.5 |
| Aplicativo | IA |
| Resolução | 1024×768 |
| Composição | LCM |
| Brilho | 650 |
| CR | 500:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL10276BC13-01C |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 6.5 inch |
| resolução | 1024(RGB)×768 , XGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 132.096×99.072 mm |
| contorno | 153×118×9.5 mm |
| superfície | Clear, Hard coating (2H), Antireflection |
| brilho | 650 cd/m² (Typ.) |
| taxa de contraste | 500:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193136% |
| tempo de resposta | 6/19 (Typ.)(Tr/Td) |
| ângulo de visão | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 6 stringsWLEDWithout Driver |
| interface de sinal | LVDS (1 ch, 6/8-bit), 20 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | IA |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276AC30-03 | NLT | 15.0 | 1024×768 |
| NL10276AC30-42C | NLT | 15.0 | 1024×768 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL10276BC20-04 | NLT | 10.4 | 1024×768 |
| NL10276BC20-18 | NLT | 10.4 | 1024×768 |
| NL10276BC30-18 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-24D | NLT | 15.0 | 1024×768 |
| AA104SH02 | Mitsubishi | 10.4 | 800×600 |
| LM104VC1T51R | SHARP | 10.4 | 640×480 |
| LM32015T | SHARP | 5.7 | 320×240 |
| LM64C219 | SHARP | 8.0 | 640×480 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| NL8060BC26-30D | NLT | 10.4 | 800×600 |
| TCG057QVLHA-G00 | Kyocera | 5.7 | 320×240 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
| UG-2864ASYDT01 | WiseChip | 2.7 | 128×64 |
