| Número da peça | NL10276BC24-19D |
| Marca | NLT |
| Tamanho | 12.1 |
| Aplicativo | IA |
| Resolução | 1024×768 |
| Composição | LCM |
| Brilho | 650 |
| CR | 600:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | NEC |
| modelo de painel | NL10276BC24-19D |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 12.1 inch |
| resolução | 1024(RGB)×768 , XGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 245.76×184.32 mm |
| contorno | 260×200×7.4 mm |
| superfície | Antiglare, Hard coating (3H) |
| brilho | 650 cd/m² (Typ.) |
| taxa de contraste | 600:1 (Typ.) |
| exibir cores | 262K (6-bit), CIE193140% |
| tempo de resposta | 6/19 (Typ.)(Tr/Td) |
| ângulo de visão | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 9S5PWLEDWithout Driver |
| interface de sinal | LVDS (1 ch, 6-bit), 30 pins |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | IA |
| NL10276AC20-03 | NLT | 10.4 | 1024×768 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
| NL10276BC20-18 | NLT | 10.4 | 1024×768 |
| NL10276BC20-18F | NLT | 10.4 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL10276BC30-34D | NLT | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G121SN01 V1 | AUO | 12.1 | 800×600 |
| LM065HB1T01 | SHARP | 6.5 | 640×240 |
| LQ104V1LG81 | SHARP | 10.4 | 640×480 |
| MC57T04L | Other | 5.7 | 320×240 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| RX215-C10 | ROGIN | 21.5 | 1920×1080 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
