| Número da peça | NL2432HC22-40J |
| Marca | NLT |
| Tamanho | 3.5 |
| Aplicativo | PDA |
| Resolução | 240×320 |
| Composição | LCM |
| Brilho | 220 |
| CR | 150:1 |
| cores | 262K |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | NEC |
| modelo de painel | NL2432HC22-40J |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 3.5 inch |
| resolução | 240(RGB)×320 , QVGA |
| modo de exibição | TN, Normally White, Transflective |
| área ativa | 53.64×71.52 mm |
| contorno | 63.5×85×3.2 mm |
| superfície | Clear, Hard coating (3H) |
| brilho | 220 cd/m² (Typ.) |
| taxa de contraste | 150:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| exibir cores | 262K (6-bit), CIE193140% |
| tempo de resposta | 7/23 (Typ.)(Tr/Td) |
| ângulo de visão | 35/35/35/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | 5S1PWLEDWithout Driver |
| interface de sinal | CMOS (1 ch, 6-bit) + SPI, 45 pins |
| tensão de entrada | 3.0V (Typ.) |
| aplicativo | PDA |
