| Número da peça | ED090NA-01H |
| Marca | Innolux |
| Tamanho | 9.0 |
| Aplicativo | PAD |
| Resolução | 1280×800 |
| Composição | Assembly |
| Brilho | |
| CR | 700:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | CHIMEI INNOLUX |
| modelo de painel | ED090NA-01H |
| tipo de painel | a-Si TFT-LCD , Assembly |
| tamanho do painel | 9.0 inch |
| resolução | 1280(RGB)×800 , WXGA |
| área ativa | 193.92×121.2 mm |
| superfície | |
| brilho | |
| taxa de contraste | 700:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| ângulo de visão | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| interface de sinal | LVDS (1 ch, 6/8-bit) |
| aplicativo | PAD |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| NL8048BC24-09D | NLT | 9.0 | 800×480 |
| YX090DKN01.0 | SEBO | 9.0 | 1280×720 |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LTL101AL06-104 | Samsung | 10.1 | 1280×800 |
| LTL106AL01-002 | Samsung | 10.6 | 1366×768 |
| N101ICE-G62 | Innolux | 10.1 | 1280×800 |
