| Número da peça | NL2432DR22-11B |
| Marca | NLT |
| Tamanho | 3.5 |
| Aplicativo | PDA |
| Resolução | 240×320 |
| Composição | LCM |
| Brilho | 50 |
| CR | |
| cores | 262K |
| luz de fundo | WLED |
| Interface | TTL |
| marca do painel | NEC |
| modelo de painel | NL2432DR22-11B |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 3.5 inch |
| resolução | 240(RGB)×320 , QVGA |
| modo de exibição | TN, Normally White, Reflective |
| área ativa | 53.64×71.52 mm |
| contorno | 66.2×91×4.7 mm |
| superfície | Hard coating (3H) |
| brilho | 50 cd/m² (Typ.) |
| taxa de contraste | 10/10(Reflective) |
| exibir cores | 262K (6-bit) |
| tempo de resposta | 15/17 (Typ.)(Tr/Td) |
| ângulo de visão | |
| tipo de lâmpada | 2S2PWLED |
| interface de sinal | CMOS (1 ch, 6-bit), 45 pins |
| tensão de entrada | 3.0/5.25/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF) |
| aplicativo | PDA |
