| Número da peça | NL10276BC20-37 |
| Marca | NLT |
| Tamanho | 10.4 |
| Aplicativo | IA |
| Resolução | 1024×768 |
| Composição | LCM |
| Brilho | 150 |
| CR | 400:1 |
| cores | 262K/16.7M |
| luz de fundo | WLED |
| Interface | LVDS |
| marca do painel | NLT |
| modelo de painel | NL10276BC20-37 |
| tipo de painel | a-Si TFT-LCD , LCM |
| tamanho do painel | 10.4 inch |
| resolução | 1024(RGB)×768 , XGA |
| modo de exibição | TN, Normally White, Transmissive |
| área ativa | 210.4×157.8 mm |
| contorno | 231.2×174.6×5.8 mm |
| superfície | Clear |
| brilho | 150 cd/m² (Typ.) |
| taxa de contraste | 400:1 (Typ.) |
| exibir cores | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| tempo de resposta | 3/15 (Typ.)(Tr/Td) |
| ângulo de visão | 45/45/40/20 (Typ.)(CR≥10)(L/R/U/D) |
| frequência | 60Hz |
| tipo de lâmpada | WLEDWithout Driver |
| interface de sinal | LVDS (1 ch, 6/8-bit) |
| tensão de entrada | 3.3V (Typ.) |
| aplicativo | IA |
